Motor Fluting Defect at NDE Insulated Bearing
NDE insulated bearing with fluting defects in 1000kw motor; carbon ring installation considered for extended life.
Like what you see?
Sign up to share your own knowledge, like posts, and engage with the community!
Another NDE Insulated bearing with fluting defects of a 1000kw motor.
Bearing life so far was 5 years since installation.
Now installed with Carbon brush on DE side but electric discharges still detected. If installing carbon ring will extend the bearing life to 2-3 years, for me that's acceptable.
What's your experience with carbon ring?
